1200-2000 Kg 45 MM Square Solid Tube Straight With 10 Hydraulic Brake Trailer Axle
Fast lube Design.
Zerk fitting on the spindle uses a rubber plug on the hub cap to grease bearings simply.
Grease your axle without pulling off your whole entire hub.
Underslung – Axle is welded with spring seats on the bottom (Axle sits on top of the springs) which Allows for lower ride height. For optimal usage, use with double eye springs
High Strength Cambered Steel Axle Tube Construction to ensure Even Tire Wear so the tires will last longer.
Powder coated black.
Hub Face (HF):
measure from one end of the axle where the lug bolts protrude out from to the other end at the same point. This is the Hub Face.
Spring Center (SC):
Measure from the middle of the spring on one axle to the center of the other spring on the same axle.
There should be about 15" difference between the Hub Face and the Spring Center measurement. (7-1/2" each side
| 5* 4.5", 6*5.5" wheel bolts pattern | | NO. | Description | QTY | option 1 | option 2 | option 3 | | 1 | axle shaft | 1 | 45mm Rd / Sq solid | 50mm Rd / Sq solid | 60*5mm round tube | | 2 | mounting plate | 2 | AT01200107 | | | | 3 | 10" brake plate | 2 | AZ013L/R | AZ004L/R | AZ026L/R | | 4 | bolt | 8 | AC00100501 | | | | 5 | washer & nut | 8 | AC00100502/3 | | | | 6 | oil seal | 2 | AC00500201 | | | | 7 | inner bearing | 2 | L68149/10 | | | | 8 | 10" hub drum | 2 | AC00500300 | | | | 9 | wheel nut | 8,10,12 | 1/2"-10UNF | 7/16"-20UNF | | | 10 | outer bearing | 2 | LM12749/10 | L68149/10 | | | 11 | flat washer | 2 | AC00500402 | | | | 12 | castle nut | 2 | AC00500403 | | | | 13 | split pin | 2 | AC00500404 | | | | 14 | dust cap | 2 | AC00500405 | | | |
| |
Choose me,do not hesitate
(1)Design team:We have a professional design team.many designs,as you choose.your sample is always welcome.
(2)Professional factory:We are manufacturer,specializing in manufacturing trailer parts for 8 years.competitive price with good quality.
(3)Sample:We can give out sample freely, the shipment charge usually paid by your side,and the fee of it will be rebound when we have formal order.
(4) Rapid response to your needs:We will be answer within 24 hours.welcome to contact us if you have any problems,we are looking forward to cooperating with you
Our Advantage
1. Our joint venture partners are American Famous axle company AXLETEK,we have make a cooperation for 6 years.So we can supply stable and high quality brakes.
2. We have Researching and Development Department in Detroit,so we are also capable of developing products according drawing or samples to meet the special requirement of our customes.
.
We are based in Shandong, China, start from 2006,sell to North America(67.00%),Oceania(20.00%),Domestic Market(6.00%),South America(00.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),Africa(00.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%). There are total about 301-500 people in our office.
